Description
Features
- Decoding & Display
- 1CH 4K HDMI input
- 2 HDMI outputs, HDMI1supports 4K/1080P HD output; HDMI2 supports 1080P HD output
- 1 VGA output and 1 BNC output
- 2CH 8MP/5MP real-time or 8CH 4MP/3MP/1080P/720P real-time or 32 CH D1 real-time
- H.265 HP/MP/BP and H.264 HP/MP/BP encoding format
- Support PS, RTP,TS,ES package format（in platform running mode）
- G.711A/G.711U
- 1 CH audio input; 1CH audio output
- Stream Mode
- A&V streams can be directly acquired from TVT IPC/DVR/NVR by SDK private protocol
- A&V streams can be acquired from NVMS platform or encoding devices by RTSP/RTP protocol
- A&V streams can be acquired from IPC by ONVIF protocol
- Decoding Control
- Support live view and playback decoding
- 1/4/9/16 screen display mode
- Splicing, picture-in-picture, roaming
- View cameras or camera groups in sequence
- Support infinite splicing display, typical splicing mode: 2×2/3×3/4×4/6×4 etc.
- Support a maximum of 24 CH output; up to 12 decoding cards inserted
- Device Management
- Support multi-level device control（Master-slave mode）
- A maximum of 64 decoders can be manageable
- Access
- Provide HTTP API protocol to third-party platform
- Support platform running mode and device running mode
- Operation and Maintenance
- Support device search
- Support WEB client access, configuration and management
- Support time zone, time and date settings
- Support IP address, subnet mask and gateway settings
- Support data port and HTTP port settings
- Support data backup and restoration
- Support remote reboot and one-button reset
- Support online and U-disk upgrade
- Support dual gigabit Ethernet ports, load balancing
- Modular and hot pluggable designs are convenient to expand and maintain and unaffected to other board card when one board card is damaged
Dimension
